Description:
- One (1) pieces packaged in a zipped plastic bag.
- One male end of 1/4″ hex connection for handles. And the other side of the female 1/4″ hex connection for the bits.
- 2 & 3/4″ in length and 3/4″ in diameter.
- Life cycle: 5,000 operations of 1/4 turns with a ±10% accuracy tolerance.
- Magnetized connection for quick selection.
- US patented: US Patent No. US8549963.
Features:
- Visually defined torque value on the adapter.
- No stop or click sound when desired torque setting is reached.
- Multi torque control, easy to use for multiple torque requirements.
- Not for loosening.
- Honored with Taiwan Excellence Award
| PN | S | Φd | L | P |
| J1 | 6.32 mm (1/4″) | 18 mm (3/4″) | 68.8 mm (2 3/4″) | 10 mm (3/8″) |
| J0 | 6.32 mm (1/4″) |
| Part No. | Torque |
| STS-ADT-IL-J1 | 15- 65 In-Lbs |
| STS-ADT-IL-J0 | 6- 25 In-Lbs |
| STS-ADT-NM-J1 | 1- 6 Nm |
| STS-ADT-NM-J0 | 0.5- 3 Nm |
